CXR emergencies drill: tension, white-out, free air

You freeze on a chest X-ray because you start at the interesting blob. A registrar does not want a tour of the bones. They want you to name the three things that kill, or to say they are not there, before you admire anything else.

This is not a full CXR method. It is a 60-second drill. Quality first, then three emergencies, then a one-line plan. Stop if any of them is present.

Confirm the patient, the date, and laterality. Treat the patient, not the image.

Before the drill: is this image usable?

Skip this and you will report a finding the image cannot support.

• Name and date match the person in front of you.

• PA vs AP, erect vs supine. AP and supine magnify the heart and hide fluid levels.

• Rotation: medial ends of the clavicles equidistant from the spinous processes.

• Inspiration: about 5–6 anterior ribs. Poor inspiration mimics a big heart and basal white-out.

• If it is unreadable, say so and repeat it. Do not invent a pneumothorax on a rotated, expiratory AP.

Write “technically limited” if quality is poor. Then still hunt the three emergencies. A bad image can still show tension.

Emergency 1: tension pneumothorax

Look at both edges, not the middle.

• Visceropleural line. No lung markings beyond it.

• Mediastinum shifted away from the lucent side.

• Flattened hemidiaphragm on that side. Distended hemithorax.

If you see shift away plus a lucent side, say it out loud. This is not a radiology meeting. Senior, oxygen, and the local decompression protocol. Do not keep scrolling the rest of the image while the patient is hypotensive.

A visceropleural line without shift is still a pneumothorax. Name it. It is not tension until there is shift and a sick patient. Do not wait for the report to tell a senior.

A skin fold is not a visceropleural line. Lung markings continue beyond a fold. If you are unsure, say you are unsure and get a senior, not a longer stare.

Emergency 2: white-out, and which way the mediastinum moved

A white hemithorax is not one diagnosis. The shift tells you which.

• Shift away from the white side: large pleural effusion (or rarely a huge mass). The fluid pushes.

• Shift toward the white side: collapse. The lung pulled.

• No shift, sick patient: mixed, consolidation, or a supine effusion. Do not force a single label.

Say the side, the shift, and what that means in one sentence.

“Left white-out, trachea pulled left: collapse until proven otherwise. Senior, airway, previous image.”

“Right white-out, trachea pushed right: large effusion. Sit the patient up, senior, do not needle it yourself.”

A white-out you call “consolidation” without checking shift is a miss.

Emergency 3: free air under the diaphragm

On an erect chest X-ray, look under both hemidiaphragms before you look at the lungs.

• Crescent of lucency under the diaphragm: perforated viscus until a senior says it is not.

• Check both sides. The right is easier. The left hides under the stomach bubble. Do not call stomach gas a perforation, and do not miss free air because you only looked right.

• If the image is supine, free air is harder. You may not see a crescent. Say the limitation. Do not reassure yourself.

If you see it, say it out loud. Senior, keep the patient nil by mouth, do not send them for a walk.

Chilaiditi (colon under the diaphragm) exists. If the “air” has haustra, pause. If you are not sure, treat it as free air and get a senior. Confirm locally. Never invent findings.

The 60-second script

Say this in your head, every chest X-ray, before ABCDE.

1. Identity and quality. Usable or not.

2. Both edges: visceropleural line? Shift away?

3. White-out? Which way did the mediastinum move?

4. Under both hemidiaphragms: free air?

If any is yes: name it, next action, senior. Then stop the drill and treat.

If all are no: say “no tension, no white-out, no free air” and only then do the rest of the image.

A chest X-ray without that sentence is theatre.

How to practise this until it is automatic

• Ten images. For each, only those four lines. Time-box 60 seconds. Do not describe the bones.

• After every real CXR on the ward, note the one question the registrar asked. That is the emergency you skipped.

• Teach the three to a peer out loud. If you cannot teach it, you do not own it yet.
