If you've ever had a VHDL design that simulates perfectly but behaves completely differently on actual FPGA hardware, there's a good chance your sensitivity list is the culprit.

The Problem

In VHDL, a process block only re-evaluates when a signal in its sensitivity list changes. Miss a signal, and your simulator won't trigger the process when it should — but the synthesis tool will infer the correct hardware anyway, creating a mismatch between what you test and what you deploy.

-- ❌ BUG: Missing 'b' from sensitivity list
process(a)
begin
  y <= a AND b;
end process;

In simulation, y only updates when a changes. If b changes while a stays constant, y won't reflect it. But the synthesized hardware is just a physical AND gate — it responds to both inputs in real time.

The Fix

Always include every signal that is read inside the process:

-- ✅ CORRECT: Both inputs in sensitivity list
process(a, b)
begin
  y <= a AND b;
end process;

Or in VHDL-2008, use process(all) to automatically include every read signal:

-- ✅ VHDL-2008: Automatic sensitivity
process(all)
begin
  y <= a AND b;
end process;

The Rules

Why This Matters for FPGA Development

On an ASIC, a simulation mismatch might get caught in weeks of verification. On an FPGA, you're flashing real hardware — if your testbench passes but the board doesn't work, you've just lost hours debugging a problem that was hiding in plain sight.

Pro tip: Run your synthesis tool's lint warnings. Most modern tools (Vivado, Quartus) will flag incomplete sensitivity lists. Treat those warnings as errors.
